PSU TMS-II IP V2021




ALIM TMS 2 is a safeguarded and controlled DC power supply, intended to be connected to the 230 Vac public distribution network.
It ensures the continuity of service of equipment in the event of a power outage
It complies with standards EN60950 – EN61000-3 – EN61000-4 – EN55014
TECHNICAL SPECIFICATIONS
- TEFABLOC plastic box
- Protection index: IP30
- W 150 x H 200 x81.2mm
- 1.81kg
- 1 Ethernet port: 100Mbps
- Communication protocol: DHCP, IPV4, SYSLOG
- Operating temperature: 10°C…35°C
- Storage temperature: 0°C…85°C
- Relative humidity in operation: 20 %…95% 30°C
- Mains voltage: 196 to 255 Vac
- Primary current: 230V 0.5A
- Frequency: 50Hz
- 2 output 12 Vdc (1.6A)
- Integrated lead battery 12V, 3.4 A/h
- Self-discharge at 25°C
- Number of cycle: 1200
